Pre-insulated copper pipes with Cross linked Foam Polyethylene (XPE) – B1 insulation for Air Conditioning Splits – ( R407 – R410)
The FomexLine Polar-Split PLUS – B1- The best solution for air conditioning split systems.
The FomexLine Polar-Split PLUS – B1 has been specially designed for air conditioning split systems, placing special emphasis on high quality and convenience during installation.
The FomexLine Polar-Split PLUS – B1 is known for its excellent quality, due to the combined use of high quality ACR copper pipes - which meet the strictest manufacturing standards and the requirements of international standards, and of Cross linked Foam Polyethylene(XPE) – B1 insulation material, well known as one of the best thermal insulation materials.
The FomexLine Polar-Split PLUS – B1 is supplied with ACR inch/mm diameter copper pipes (ASTM B280 and/or EN 12735) and 6mm - 9mm-thick insulation wall coated with an aesthetic white external film that provides protection to the pipe and the insulation from UV radiation and mechanical damages.
FomexLine Polar-Split PLUS – B1 is the most suitable pre-insulated copper pipe for air conditioning splits
Every meter of FomexLine Polar-Split PLUS – B1 is marked with the relevant dimensions and other pertinent details about the product for the convenience of the plumber, as shown in the following example:
1m FOMEXLINE POLAR – SPLIT PLUS XPE DIN 4102- B1 INSULATION UV 5/8” x 1.0mm.EN12735-1 R407-R410
FomexLine Polar-Split PLUS – B1 saves expensive time and manpower effort during installation.
FomexLine Polar-Split PLUS – B1 is supplied in 25 or 50-meter coils, according to customer requirements.
* FomexLine Polar-Split PLUS – B1 can be bent with the help of our Universal Bending Machine.
FomexLine Polar-Split PLUS – B1- TECHNICAL DATA
Copper pipes |
CU - DHP 99.9% inch / mm diameter ,ASTM-B280 and/or EN 12735 |
Insulation Type |
Cross linked Foam Polyethylene (XPE) |
Insulation structure |
closed cells |
Insulation wall thickness |
6mm - 9mm |
Temp. Range |
-60°c - +120°c |
Water Vapor diffusion |
5000 |
Thermal conductivity |
0.036w/m*k at 20°c |
Fire Rating- |
Class DIN4102-B1 self - extinguishing |
External Coating |
white with UV protection |
|
|
|
|
Copper Pipes Diameter |
inch |
1/4" |
5/16" |
3/8" |
1/2" |
5/8" |
3/4" |
7/8" |
mm |
6 |
8 |
10 |
12 |
15 |
18 |
22 |
Insulation Wall Thickness |
mm |
6 |
9 |
6 |
9 |
6 |
9 |
6 |
9 |
9 |
9 |
9 |
External diameter Copper insulation |
mm |
18 |
24 |
20 |
26 |
22 |
28 |
25 |
30 |
34 |
37 |
40 |
Copper pipe |
Kg/m |
0.118 - 0.143 |
0.152 - 0.200 |
0.185 - 0.257 |
0.255 - 0.314 |
0.366 - 0.410 |
0.485 - 0.510 |
0.599 - 0.678 |
Water Content |
Vl/m |
0.016 |
0.029 |
0.046 |
0.093 |
0.155 |
0.233 |
0.327 |
|
